Leviton OSSNL-IDW Decora Passive Infrared Wall Switch Occupancy Sensor, LED Adjustable Night Light, 180 Degree, 1200 sq. ft. Coverage, White
by Leviton

List Price: $65.59
Buy Used: from $51.99 (click here)
Category: Tools
See more product details

(Click here)

Product Details

• For use in conference rooms, classrooms, small offices, lounges, hotel/hospital/office restrooms
• LED Nightlight offers "Guide Light" functionality with an adjustable illumination and a setting for either continuous or dimmed mode
• Horizontal field-of-view may be adjusted between 180 degrees and 32 degrees of arc by using patented integral blinders located on either side of the lens.
• Proprietary segmented (vandal-resistant) Fresnel lens provides optimum sensitivity and performance, designed with an extensive "small motion" area where even slight body movements will be detected
• Manual delayed-off time settings: 30 seconds test mode, 30 minutes, 1 hour, 2 hours

• Leviton ODS15-IDW Decora Passive Infrared Wall Switch Occupancy Sensor, 180 Degree, 2100 sq. ft. Coverage, Self-Adjusting, White
• Leviton 80409-W 2-Gang Decora/GFCI Device Decora Wallplate, Standard Size, Thermoset, Device Mount, White
• Leviton 80301-SW 1-Gang Decora Plus Wallplate Screwless Snap-On Mount, White
• Leviton OSWWG-W Wire Guard for Wall Mount Occupancy Sensors

Description of Leviton OSSNL-IDW Decora Passive Infrared Wall Switch Occupancy Sensor, LED Adjustable Night Light, 180 Degree, 1200 sq. ft. Coverage, White

The OSSNL-IDW Designer Occupancy Sensor Wall Switch At a Glance: Passive infrared technology Motion detection with adjustable 180-degree field of view Proprietary Fresnel lens for optimum sensitivity 4 time delay settings Adjustable LED NightLight 5-year limited warranty

Light is motion- or touch-responsive; "off" mode deactivates motion sensor for set amount of time.

"Small-motion" detection is sensitive to slight movements within 180-degree field of view.

Passive Infrared Technology Detects Motion
The OSSNL-IDW works via a passive infrared sensor to automatically switch lights on. The lights will remain on until no motion is detected and the preset wait time has expired--you can choose from among four time delay settings--30 seconds, 30 minutes, one hour, or two hours.

The occupancy sensor features a proprietary segmented Fresnel lens that provides optimum sensitivity and performance. Designed with an extensive "small-motion" area, the lens will detect even the slightest body movements within its horizontal 180-degree field of view.

For convenience, the sensor has two independently operating blinders that you can program to narrow the field of view (between 180 and 32 degrees) and prevent unwanted activation from traffic in adjacent space.

Push-Button Toggling Between On and Off Modes
The OSSNL-IDW features a push-button switch for manual selection of on and off modes. In 'on' mode, the lights will remain on in the presence of motion; in the absence of motion, the sensor unit will time-out and turn the lights off.

In 'off' mode, the lights will stay off regardless of motion detected, until the time-out expires. After the time-out expires, the lights will turn on (auto-on mode only) with the next detected motion. This feature is especially useful when you're making slide or film presentations.

Adjustable LED Night Light Guides You in the Dark
In addition to a motion sensor, the OSSNL-IDW features an LED NightLight. The NightLight operates separately from the lights that are controlled by the sensor, and it will turn on when its photocell detects ambient light that is less than one foot-candle. It will turn off when the ambient light exceeds five foot-candles.

The LED NightLight is adjustable for continuous mode or dimmed mode. In dimmed mode, the LED adjusts to five percent of full brightness after motion has not been detected for two minutes. You can choose the amount of illumination with a simple dial setting.

In continuous mode, the LED NightLight will go to full brightness (per your dial setting) when occupancy is detected and when the ambient light level is less than one foot-candle. It will return to the low setting when occupancy is no longer detected and the ambient light level is less than one foot-candle.

Ideal for Hospitals, Hotel Rooms, and More
The OSSNL is perfect for use in hospitality and health care facilities that have either auto or manual 'on' settings with adjustable time delays of 30 seconds to two hours.

It is also ideal for hotel rooms, conference rooms, class rooms, small offices, lounges, storage areas, bathrooms, and anywhere else you want automatic lighting control that will give you energy savings, improved safety, and convenience.

If you're looking to save energy, you'll be happy to know that the LED NightLight consumes less than one half of a watt while providing guide lighting when room lights are off.

Easy Installation
The OSSNL-IDW is factory preset to deliver optimum performance in a wide variety of applications without any adjustments during installation. The unit can replace a single-pole wall switch mounted in a standard wall box, and it is gangable with other units. For further convenience, the unit features zero-crossing circuitry to enhance reliability and provide long-term operation. The OSSNL-IDW has a maximum coverage area of 1,200 square feet.

In order to operate, the OSSNL-IDW must have a neutral connection and must be properly grounded. Also, it should be positioned at least four feet away from HVAC registers. Note that when the unit is powered up, it will take approximately one minute to begin normal operation.

The OSSNL-IDW is UL and cUL listed and is NOM and CEC Title-24 Compliant. It is backed by a five-year limited warranty.

What's in the Box
OSSNL-IDW occupancy sensor wall switch with night light.

Motion-activation and time-delay save energy and provide security in hotels, offices, bathrooms, and more.
